Application Fields
Packaging | Food | Pharmaceuticals | New Materials | Chemical Industry | Printing
Suitable for measuring the static and kinetic coefficients of friction (COF) of materials during sliding, including plastic films and sheets, rubber, paper, paperboard, woven bags, fabric styles, metal composite tapes for communication cables, conveyor belts, wood, coatings, brake pads, windshield wipers, shoe materials, wheels, and tires. By measuring the slipperiness of materials, users can control and adjust production quality indicators to meet application requirements.
The specimen is cut into two pieces: one is fixed on the test platform with a clamp, and the other wraps around the sled. The sled is then attached to the sensor’s hook. Under the traction force, the sled moves, causing relative motion between the two test surfaces. The force signal detected by the sensor is amplified and recorded to calculate and display both the static and kinetic coefficients of friction simultaneously.
- High precision with accurate test results.
- 7-inch touchscreen display for intelligent interaction. Equipped with a next-generation smart OS, it provides a smartphone-like intuitive interface with clear operational logic.
- Both the test platform and the sled are degaussed and tested for residual magnetism, effectively reducing system measurement errors.
- Features a "point capture" function to record data at specific intervals.
- Supports batch storage of 20 data groups with simultaneous printing.
- Calibration parameters are password-protected to prevent unauthorized or accidental modifications.
- Measures both static and kinetic coefficients of friction in a single test run.
|
Item
|
Parameter
|
|
Force Range
|
0-10N (Customizable）
|
|
Accuracy
|
Grade 0.5
|
|
Specimen Thickness
|
≤2mm(Customizable)
|
|
COF Range
|
0.001~0.999
|
|
Sled Size
|
63mm*63mm
|
|
Test Speed
|
100mm/min (150mm/min optional)
|
|
Sled Mass
|
200g(Customizable)
|
|
Platform Size
|
200mm*470mm
|
|
Measurement Error
|
±2%
|
|
Power Supply
|
AC 220V/50 Hz
|
|
Dimensions
|
470mm*340mm*260mm
|
|
Standard Configuration
|
Mainframe, Micro-printer, Power Cable, One Sled
|
We provide detailed product technical specifications, application scenarios, and other relevant information to help customers select the most suitable instruments and equipment. We also offer comprehensive support for solution design, sample testing, on-site inspections, and other professional services.
We collaborate with customers to clearly define all contract details, including pricing, delivery schedule, and payment terms, and execute formal contracts. We deliver thorough operation and maintenance training to ensure customers can use the instruments correctly and efficiently. Additionally, we assist with acceptance procedures and perform rigorous pre-shipment debugging and testing on every instrument to guarantee full compliance with contract requirements.
In addition to a one-year warranty period, we provide lifelong remote technical support to resolve any usage issues. We also offer regular maintenance services and respond promptly and efficiently to specific customer needs.
